A simple and easy-to-use raygui icons editor.

Useful for tools icons customization. The best tool companion for rGuiLayout and rGuiStyler.

rGuiIcons can be used for free as a WebAssembly online tool and it can also be downloaded as a standalone tool for Windows, Linux and macOS with some extra features.

WARNING: This tool targets raygui 4.0

rGuiIcons Features

  • Icon editing and preview at multiple sizes
  • Cut, copy, paste icons for easy editing
  • Undo/Redo system for icon changes
  • Save and load as binary iconset file .rgi
  • Export iconset as an embeddable code file (.h)
  • Export iconset as a .png black&white image
  • Icon name ids exported as standard PNG chunk (zTXt)
  • Multiple UI styles for tools reference
  • +200 custom icons for reference and basic edition
  • Completely free and open source

rGuiStyler Standalone Additional Features

  • Command-line support for .rgi/.h/.png batch conversion
  • Completely portable (single-file, no-dependencies)

rGuiIcons Usage

The tool is quite intuitive, the expected steps to follow are:

  1. Choose the icon to edit from icons panel
  2. Edit the icon pixels in the right panel
  3. Select next icon for edit or export set/individual icon

NOTE: Icon changes are previewed in real time in the same tool!

Once icons have been created/edited, they can be saved as a raygui-ready icon set (.rgi), exported as an embeddable .h code file or exported as a .png image. Note that the .png contains the icons ids information in a standard chunk (tEXt/zTXt).

  • raygui icon set file (.rgi) can be loaded by raygui using the function GuiLoadIcons().

  • raygui icon set code file (.h) can be embedded into a raygui-based application just defining:

#define RAYGUI_CUSTOM_ICONS     // Custom icons set required
#include "gui_iconset.h"        // Custom icons set provided, generated with rGuiIcons tool
#include "raygui.h"

rGuiIcons Standalone comes with command-line support for batch conversion. For usage help:

rguiicons.exe --help

rGuiIcons License

rGuiIcons source code is distributed as open source, licensed under an unmodified zlib/libpng license.

rGuiIcons binaries are completely free for anyone willing to compile it directly from source.

rGuiIcons Standalone desktop tool is distributed as freeware.

In any case, consider some donation to help the author keep working on software for games development.

Copyright (c) 2019-2022 raylib technologies (@raylibtech) / Ramon Santamaria (@raysan5)


Download NowName your own price

Click download now to get access to the following files:

rGuiIcons v3.0 Windows (x64) 360 kB
rGuiIcons v3.0 Linux (x64) 355 kB
rGuiIcons v3.0 macOS (x64 + arm64) 701 kB
